Acoustic Cum Fire Wooden Door FD-120
ESL-ACWFD-120
At Envirotech Systems Limited, we are a leading Wooden Fire Doors Manufacturer in India, offering high-quality, certified FD-120 acoustic cum fire-rated wooden doors. Our doors are meticulously engineered to resist fire for up to 120 minutes while also delivering superior sound insulation—ensuring both life safety and comfort.
In modern architecture, the fusion of aesthetics, fire safety, and acoustic control is not just a luxury—it’s a necessity. Especially in commercial, residential, institutional, and industrial buildings, the demand for fire-rated solutions that also maintain a pleasing visual appearance is rapidly growing. This is where Acoustic Cum Fire Wooden Door FD-120 plays a pivotal role.
All our FD-120 acoustic wooden fire doors are manufactured in-house using CNC-based fabrication, automated pressing, and quality control checks. Our doors are tested at NABL-accredited labs and conform to national and international fire and acoustic standards, giving you complete peace of mind.
🔥 Acoustic Cum Fire Wooden Door FD-120
FD–120 Wooden Fire Doors are designed to withstand fire for up to 120 minutes, preventing the spread of flames and smoke. These doors are essential in commercial, industrial, and residential buildings to ensure life safety and structural protection.
What is an Acoustic Cum Fire Wooden Door FD-120?
An Acoustic Cum Fire Wooden Door FD-120 is a specially engineered wooden door system that combines fire resistance up to 120 minutes with acoustic performance. This means the door can:
- Contain the spread of fire and smoke for up to two hours
- Offer noise reduction up to 40 dB
- Enhance interior aesthetics through wood finishes
- Comply with international fire safety and acoustic norms
These doors are ideal for spaces where elegance, privacy, and safety are key—such as hospitals, hotels, data centers, boardrooms, schools, and residential high-rises. Our FD-120 doors are engineered using specially treated hardwood, multi-layered fire-resistant core materials, and high-performance intumescent seals that expand when exposed to heat, creating a robust barrier against smoke and flames.
🔑 Key Features of Acoustic Cum Fire Wooden Door FD-120
Tested as per IS 3614 Part 2, BS 476 Part 20 & 22, and EN 1634-1, our wooden fire doors can resist fire, heat, and smoke for two full hours, ensuring critical evacuation time during emergencies.
The door core is filled with high-density mineral wool or acoustic infill material to offer noise reduction, ideal for privacy in sensitive areas.
Our fire-rated doors come in various finishes like natural wood veneer, laminate, PU polish, and melamine, maintaining architectural elegance without compromising performance.
Equipped with intumescent fire seals and smoke seals, our doors block smoke, gases, and flames from passing through door gaps.
The core of the FD-120 door is pressure-treated hardwood or mineral core board laminated with fire-rated MDF or HDF, ensuring long-term structural integrity.
We offer fire-rated glass vision panels that maintain fire resistance while allowing visibility—ideal for hospitals and commercial offices.
Our FD-120 wooden fire doors come with ISI-certified and CE-marked hardware, including heavy-duty hinges, panic bars, mortise locks, and fire-rated door closers.
Technical Specification
- Type of Door: Fire Door.
- Door Leaf Type: Single Leaf Door / Double Leaf Door.
- Fire Rating: 120 minutes.
- STC Level: 45-51
Insulation: Fire Rated Insulation + Sound Dampening Material - Test Standard: FR + Acoustic Standards
- Thickness: 86mm
- Recommended Hardware: SS Ball Bearing Hinges-SS-304, Fire Rated Door Closer, Tower Bolt, Flush Bolt, Fire Seal.
- Finish: Laminate/Veneer
Optional Hardware
- Mortise lock with cylinder & handle.
- Mortised SASH lock with cylinder & lever handle.
- Fire Rated Panic Bar.
- Vision Glass.
- Access Control.
- Note: Wide Options available.
Applications of Acoustic Cum Fire Wooden Door FD-120
Acoustic Cum Fire Wooden Door FD-120 is widely used across commercial, industrial, and residential spaces to enhance fire safety. It is ideal for stairwells, corridors, emergency exits, data centers, hospitals, hotels, and high-rise buildings.
