Metal Fire Door FD – 60
ESL-MFD-60
Fire safety is a critical aspect of any residential, commercial, or industrial building. At Envirotech Systems Limited, we specialize in manufacturing high-quality Metal Fire Rated Doors that help contain fire and smoke, giving occupants time to evacuate and minimizing structural damage. One of our most popular solutions is the Metal Fire Door FD – 60, designed for environments where 60-minute fire protection is essential.
A 60-minute metal fire rated door, also known as FD-60, is specially engineered and tested to resist fire for at least 60 minutes. This rating indicates the door’s ability to remain structurally stable and limit the passage of fire and hot gases during a fire event.
These doors are constructed using robust steel materials combined with a fire-resistant core such as mineral wool, vermiculite, or honeycomb. The door is finished with fire-rated hardware, smoke seals, and optional vision panels with fire-rated glass.
🔥 Metal Fire Door FD–60 (60 Minutes Fire Rated)
FD–60 Metal Fire Doors are designed to withstand fire for up to 60 minutes, preventing the spread of flames and smoke. These doors are essential in commercial, industrial, and residential buildings to ensure life safety and structural protection.
What is Metal Fire Door FD - 60?
The Metal Fire Door FD – 60 is a certified Fire Door engineered to withstand fire exposure for up to 60 minutes. It serves as a passive fire protection barrier, helping to restrict the spread of flames and smoke within a building. This fire-rated door is crafted from galvanized steel and internally filled with fire-resistant materials such as mineral wool, offering both structural integrity and thermal insulation.
🔑 Key Features of Metal Fire Door FD – 60
Certified to resist fire for up to 60 minutes, preventing the spread of flames, smoke, and heat.
Made with galvanized steel or mild steel for enhanced durability and structural strength.
Filled with Rockwool, Honeycomb, or Ceramic Wool to provide high thermal insulation and fire resistance.
Designed with intumescent seals and optional smoke seals to block smoke infiltration during a fire.
Equipped with fire-rated locks, hinges, panic bars, and door closers to meet fire safety regulations.
Available with or without vision panels using fire-rated glass; can be powder-coated in custom colors.
Manufactured as per IS 3614 / BS 476 / UL 10C standards for fire-rated doors.
Ideal for stairwells, corridors, emergency exits, data centers, and industrial facilities.
Optional sound insulation and eco-friendly material options available.
Supplied as pre-hung door sets for quick installation; low maintenance over life cycle.
Technical Specification
- Type of Door: Fire Door.
- Door Leaf Type: Single Leaf Door / Double Leaf Door.
- Fire Rating: 60 mintues.
- Insulation: Fire Rated Insulation.
- Test Standard: BS-476 Part 20-22, IS-3614 Part 2.
- Thickness: 42mm
Recommended. - Hardware: SS Ball Bearning Hinges-SS-304, Fire Rated Door Closer, Tower Bolt, Flush Bolt, Fire Seal.
- Finish: Powder Coating in Required RAL Shade Code/ Wood Grain Finish.
Optional Hardware
- Mortise lock with cylinder & handle.
- Mortised SASH lock with cylinder & lever handle.
- Fire Rated Panic Bar.
- Vision Glass.
- Access Control.
- Note: Wide Options avaliable
Applications of Metal Fire Door FD – 60
Metal Fire Door FD – 60 is widely used across commercial, industrial, and residential spaces to enhance fire safety. It is ideal for stairwells, corridors, emergency exits, data centers, hospitals, hotels, and high-rise buildings.
